Product Description
Features
Safe lithium iron phosphate battery cell
≥2,000 cycles, 10+ years service life
Each module is equipped with an independent BMS system
Small size and lightweight design
Standard design, handle configuration, fast stacking
Specifications
| Item name | LiFePO4 PV Energy Storage Battery Pack |
Model number | ESS48200 |
| Battery type | LiFePO4 cell |
Nominal voltage | 51.2V @ 16S |
Nominal capacity@0.2C | 200Ah |
Min.capacity@0.2C | 194Ah |
Nominal energy | 10.24kWh |
Dimensions(L*W*H) | 600*600*850mm |
Weight | Approx. 105Kg |
Operating voltage range | 42.0V~54.0V |
Recommended charging voltage | 52.5V~54.0V |
Max.charging current | 100A |
Charging current limit in parallel connection （programmable NO /OFF） | 20A |
Max. continuous discharging current | 100A |
| Max. peak discharging current | 120A(<3S) |
| Discharging cut-off voltage | 44.8V |
| Long Cycle Life(@25℃,0.2C,80%D0D) | Over 2000 Cycles |
Product Details
There are many other styles for you to choose below
Custom Services
Standard Lineup
• Operating voltage 48V and 51.2V
•Typical Basic Storage Battery 48V100Ah while more options from 48V10Ah/20Ah/30Ah/50Ah/70Ah
• Optional capacity in cabinet size 200Ah ~ 600Ah
Custom Manufacturing
1. Custom Battery System is available through the integration of more basic storage battery
2. Battery Systems of different operating voltage, capacity, etc.
Applications
Practical Application Cases
Why Choose MANLY Battery?
1. Focus on the lithium battery industry for more than 12 years of technical research & development
2. MANLY Battery insists on being market-oriented and backed by a strong R&D team
3. MANLY battery guarantees that the battery provided to you is good for use, In addition, they can be infinitely customized to meet your changing needs
4. Passed ISO9001:2015 certification and EC, ROHS, KC, BS, MSDS, UN38.3 certificates
MANLY Battery Factory Overview
Packaging and Shipping
FAQ
Q: Does MANLY Battery a factory or trading company?
A: We are a factory and own 3 different production bases with over 2,000 workers in total.
Q: Do you have samples in current stock?
A: Usually we do not, because most of our battery products are customized, different customers have different requirements, even the same voltage and capacity, their other parameters may be different.
Q: Can I have a sample order?
A: Yes, samples are available for testing and quality checking, but usually not free at first.
Q: How long I can get the specific price?
A: After receiving your inquiry, our sales will quote to you within 24 hours excluding the public holiday.
Q: What certifications does your battery products can pass?
A: Our battery products support passing the certificates of UL, CE, RoHS, FCC, IEC, UN38.3, MSDS.
If the corresponding model is not found on our website, please contact our online sales engineer or email at sales@manlybatteries.com, we can quickly provide you with a variety of customized and personalized service requirements from product design to protection circuit design.
