OEM Custom Capacity Accept LiFePo4 12V 24Ah Battery Pack
Features
1. Safety: safest Lithium battery, CE UL approved, built-in PCM/BMS
2. Clean and Green energy, no toxic material contained
3. Long life cycle:> 2000 times, 6-8 times of lead-acid battery
4. No memory effect, highly efficient, charge anytime
5. Small size and lightweight: 1/2 size& weight of the lead-acid battery
6. Good performance at high temperature
7. Low self-discharge rate: < 3% monthly
8. Factory direct sale high quality lifepo412V 24AH battery
Parameters
| Electrical Characteristics | Nominal Voltage | 12.8V |
| Nominal Capacity | 24Ah | |
| Energy | 300Wh | |
| Internal Resistance | ≤10mΩ | |
| Cycle Life | >2000 cycles@1C 100% DOD | |
| Months Self Discharge | <3% | |
| Efficiency of Charge | 100%@0.5C | |
| Efficiency of Discharge | 96-99% @1C | |
| Standard Charge | Charge Cut-off Voltage | 14.6±0.2V |
| Charge Mode | 0.2C to 14.6V, then 14.6V charge current to 0.02C(CC/CV) | |
| Standard Charge Current | 4A | |
| Max. Charge Current | 20A | |
| Standard Discharge | Continuous Current | 20A |
| Max. Pulse Current | 40A(10S) | |
| Discharge Cut-off Voltage | 10V | |
| Environmental | Charge Temperature | 0℃ to 45℃(32F to 113F)@60±25% Relative Humidity |
| Discharge Temperature | -20℃ to 60℃(-4F to 140F)@60±25% Relative Humidity | |
| Storage Temperature | 0℃ to 40℃(32F to 104F)@60±25% Relative Humidity | |
| Water Dust Resistance | IP54 | |
| Mechanical | Cell&Method | 4S |
| Case | PVC package | |
Dimensions(in/mm) | Customized size | |
eight(lbs/kg) | 2.5kg |
Advantages
1. Ultra-lightweight
Lithium 12V 24Ah Battery is up to 80% lighter than equivalent 12V 24Ah lead-acid batteries
2. Higher power
High cranking current, up to 50 times the battery capacity (more than 3 times the power of lead-acid batteries)
3. Longer cycle time
About 3500+ charge and discharge cycles compare 300/400 with the lead-acid batteries
4. Respect for the environment
Eco-friendly and non-polluting batteries, no acid or heavy metals (Lead, cadmium, mercury)
5. Fast charging, slow self-discharge
Reduced charging times, can bear high current (up to 10 times the battery capacity), and have a reduced self-discharge
MANLY battery manufacture offers high-level safety battery through assembled with high quality A grade cell by our own production bases.
MANLY wide range battery has been designed to replace lead-acid batteries, by offering a higher energy density for an equivalent weight and size. Outstanding Discharge properties and Storage Capacity, etc
With many advantages: the high reliability, long lifespan, and no pollution operation, good replacement for lead-acid batteries in a wide range of applications like solar energy storage, AGV, motorcycle battery, forklift battery, e-vehicle battery, etc.
Automatic testing with advanced equipment for performances of battery packs before delivery;
Application
Our Projects
We have many successful projects such as ESS storage energy system, household solar system, commercial solar system, solar street light, AGV applications, golf carts, etc. MANLY professional engineer team have more than 10 years experience in the lithium battery field and R&D can custom any best lithium battery solutions per request which are a good replacement for lead-acid battery, etc.
Advanced Automatic Equipment ensures excellent battery pack processing
Our lithium battery pack wins a super long cycle lifespan, high charge & discharge rate, high energy density, super stable performance, and safety in different temperature environments. We pay much attention to each step which ensures providing our client with the senior quality battery pack. which gained high reputations among our clients!
Battery cells capacity sorting: ensure the precision of cell balance as ensure assembled the best capacity and quality of battery pack.
Battery cells IR testing: Undertaking internal resistance testing ensures the best consistency for the best battery pack combination.
Battery pack multi testing: This ensures the best power performance and prolongs the lifespan of the battery pack.
Automatic Welding: This can avoid insufficient welding by ensuring high-quality battery pack assembling.
Spot Automatic welding: By using full/semi-automatic production equipment to improve production efficiency and product quality.
Comprehensive Testing: Using automatic test equipment, comprehensive test of large batteries, cycles, IR, consistency, accurate data, perfect curve, ensure 100% qualified.
Professional Engineer team
Own an excellent engineer team with more than 10years’ rich experience in lithium battery R&D, design excellent battery solutions for clients! Our mechanical and electrical engineer is professional in structural, software, and hardware for designing the best-customized battery, which ensures our battery pack complies with the most competitive cells, battery pack, and BMS solutions with advanced lithium technology.
Packing & Delivery
Package: With good quality pearl wool, UN cartons / Plywood, plastic pallet.
Standard batteries lead time: Samples: 15-20 days, Bulk order: 25-30 days.
Customized batteries lead time: Samples: 30-40 days, Bulk order: 30-40 days.
