MANLY possesses technologies and experiences to provide fully integrated products & solutions for lithium-ion-based green energy applications, including Medical devices, E-mobility, Energy Storage Systems, Defense & Security, Industrial Electronics, and many other applications.
Every battery MANLY assembles is 100% tested for functionality before it is submitted to final inspection. This ranges from a voltage and polarity test for batteries to pull testing for any battery with wire leads and connector, and to a charge/discharge system test for rechargeable batteries.
PHYSICAL
| MODEL | Type | LENGTH | WIDTH | HEIGHT | WEIGHT |
| MLP15 | LiFePo4/LFP | 135mm | 30mm | 70mm | 0.94kg |
ELECTRICAL
| Type | Voltage(V) | Capacity(Ah) | Energy(Wh) | Cycle |
| 3.2V/15Ah | 3.2 | 15 | 48 | ＞3000 |
| Continuous Discharge Current | Continuous Charge Current | Operation Temp | ||
| 15A | 7.5A | -20℃ | 55℃ | |
| Initial SOC | Shell | Charge Temperature Range | ||
| 20% ~ 45% | Blue PVC | 0℃ ~ 55℃ | ||
CHARGING
| Voltage Settings (at 25°C) | ||
System Voltage | Cut off Discharge Voltage | Full Charge Voltage |
| 3.2V | 2.5V | 3.65V |
| Do not install batteries in a sealed or non-ventilated compartment. Constant under or overcharging will damage the battery and shorten its life as with any battery. | ||
OUR ADVANTAGES
1. Samples testing is accepted, samples can be free according to the battery type
2. Sample time is about 25~30 working days
3. Delivery time is about 20~25 working days after check all the details
4. Price term: EXW, FOB, CIF, C&F, etc
5. Payment term: 100% deposit
6. OEM and ODM are welcome
The Process of LifePo4 Battery Packs Customize
1. Battery Application:
AGV, E-bike, E-motorbike, Rickshaw, Solar Street Light, UPS System, Robotic, Energy storage system, Mobile Tower Station, etc
2. Continuous Working Current and Peak Current:
Continuous / Constant Working Current means the current of the device working in general, if you don’t have an engineer to know about it, let us know the watt of the device.
Peak Current also called Max current, is mostly used to describe current that may happen in seconds when the device just start and may have a high drain current requirement
3. Working Hours
Please kindly let us know the capacity of the battery you want to make.
Working hours are very important as that will decide the BMS, as well as battery size.
4. Size
In some cases that you might have already wanted the battery to be in-house, let us know the MAX dimension is left for the battery
5. Casing
There are mainly 3 types of outer casing: PVC, ABS Plastic, metal
6. Connector Type and Model
Like JST, JSH. Others like 55*25 type
