Usage Notes:
Our core cell is 3.2V 3.4Ah and 3.2V 6Ah, other cel types (eg. 48V 12Ah, 36V 20Ah) are all reconfigurable. The two battery cells, with normal voltage of 3.2V and capacity of 3.4Ah/6Ah can be assembled as high power LiFePo4 modules. It can be used individually and can be connected in serial or parallel to achieve ideal voltage and capacity.
Product advantages
1) High energy density, 150wh/kg, 270wh/L
2) Light weight, about 1/3 the weight of lead-acid batteries
3) Environment-friendly, green battery: do not contain any heavy metal, rare metal, non-toxic, no pollution, accord with European ROHS standard, it is a green battery.
4) superior in safety: non-explosive in short circuit, over charged, outside damage
5) No memory effect: can charge and discharge in any condition, no need to completely discharged or charged, do not effect it's quality.
6) Long cycle life: 2000 times cycles life (1C, ≥80% capacity) which is 7 times of lead acid battery
7) low self discharge : ≤3% of nominal capacity /month.
Specifications
Nominal Voltage | 48V | Nominal Capacity | 30Ah |
Charge cut-off voltage | 57.6V | Discharge cut-off voltage | 40V |
Max charge current | 1C | Charge method | CV/CC |
Continuous discharge current | 50A | Standard charge/discharge current | 6A@0.2C |
Size | adjustable | Weight | 19kg |
Cycle life | ≥2000 | Warranty | 3 years |
Product purpose
Storage battery: Solar Energy Storage, Solar Street Light, Wind Energy Storage, Telecommunications Base Stations, Weather Base Station, UPS(Uninterrupted Power Supply), General Energy Storage (Such as: Back-up Power, Miner’s lamp, portable power supply, digital products etc.)
Power battery: Electric Vehicles (Electrical Bicycles, Electrical Motor, tourist cars, golf carts, beach cars, E-boats, scooters), Hybrid Electric Vehicles (Plug-in HEVs), Power tools and robots etc.
