Features:
48v 200ah lithium battery
1.【Grade A LiFePO4 Cells】48v 200ah lithium battery adopt advanced Grade A LiFePO4 Cells with UL certificated, which have higher energy density, more stable performance and greater power. Besides, the BMS with equalization to control the consistency of the cells inside the battery, which to extend the battery lifespan. It also with FCC, CE certificates, and a 5-year warranty will set you free from the battery security concerns.
2.【3-4 Times higher Energy Density】With a new upgraded metal case providing more solidity than a regular ABS case, heat dissipation easier, 48v 200ah lithium battery are the perfect replacement of your old battery system. With the higher around 133Wh/L energy density, It is a 3-4 times that of lead-acid batteries in the same dimension. Lasting for around 4000-15000 cycles, which means it can be used around 10 years.
3.【10 Days Nonstop Power Supply】LiTime lithium battery can power your home for up to 10 days without using any utility power (Ensure the demand of min. electricity per day is 0.5kWh), allowing you to avoid grid outages. Meanwhile, with the 100A BMS and 4800W output, you can easily power most heavy-duty appliances at the same time, including dryers, air conditioners. It supports to be connected in parallel for higher power (Max. in 4P for 19.2kW).
4.【4X Charging Speed & 1/2 Space Saving】 48v 200ah lithium battery has a max. 4.8kWh energy, which is equivalent to 4*12V 100Ah LiFePO4 batteries in series (or even 8*12V 100Ah AGM batteries in series). It greatly reduces charging time from 20hrs to 5hrs (with 20A charging current), because you do not need to charge the 12V 100Ah battery one by one once you just receive the batteries. And it can save your 1/2 space, providing you with peace of mind and beauty because there are no more tangled connection wires to bother you.
Parameters:
| Battery item | 48v 200ah lithium battery |
| Brand name | MANLY |
| Model No. | MLP48200A |
| Electric Characteristics | |
| Nominal Voltage | 48V |
| Nominal Capacity | 200AH |
| Minimum Capacity | 200AH |
| Charge Cut-off Voltage | 54.75V |
| Discharge Cut-off Voltage | 37.5V |
| Charging and Discharging Parameters | |
| Continuous Discharge Current | 50A |
| Discharge Peak Current | 108A(Could be customized) |
| Cycle Life | 2000times≥100% |
| Charge style | CC/CV |
| Weight/size | Customized |
| Charge Temperature Range | 0℃~45℃ |
| Discharge Temperature Range |
-20~60℃ |
| Storage Temperature |
-20°C ~ 45°C |
| OEM/ODM | Welcomed |
| Protection Level | IP56 |
| Communication | Customized |
| Housing materials | Metal/ABS |
Let us know your request and we will handle the rest for you: Customize for particular usage and realize the particular function.
MANLY Battery Factory Overview
Why Choose MANLY Battery?
1. For any defectives, we provide free ones along with your next order.
2. We have a complete production line from the battery cell to the battery pack.
3. All of our products are certified with FCC, CE, ROHS, EMC, MSDS, UN38.3 and etc.
4. Worldwide product liability insurance.
Customers Feedbacks
Applications Of 48V Lithium Battery
Packaging & Shipping
FAQ
Q: What is the lead time of the batch order?
A: Generally, about 45 days after receipt of deposit and sample confirmation, depending on different voltage and capacity.
Q: What are the terms of payment?
A: For bulk orders, a 50% deposit will be paid first, and the remaining 50% will be paid before delivery.
Q: What kind of certificates can be provided?
A: UL, IEC, CE, ROHS, UN38.3, MSDS, etc.
Q: Does your battery have a real capacity?
A: All of our batteries are Class A, the actual capacity value ≥99% of the nominal capacity value.
