Features:
24V 60Ah pack
24V 60Ah consists of many Lifepo4 cells mounted together in a honeycomb structure and spot welded together and with good quality steel stainless case,more hard.
Product Application
24 Volt lithium iron phosphate battery can be widely applied to many applications,such as AGV/E-scooter/Motorbike/Tricycle/Golf cart.
Specification:
Items | Specifications |
Voltage | 25.6V |
Capacity | 60Ah |
Standard Charge Current | 12A (0.2C) |
Max. Charge Current | 60A (1C) |
Battery management System (BMS) | 30amp continuous 60amp burst BMS(we will use BMS according to your requirements) |
Continuous Discharge Current | 30A |
Peak Discharge Current | 60A |
Full Charged Voltage | 29.2V(3.65V per cell) |
Charge Cut-off Voltage | 31.2V (3.9V any single cell) |
Discharge Cut-off Voltage | 20V (2.5V per cell) |
Net Weight | Around 15.2kg |
Dimensions | Customize |
Operating Temperature | Charging: 0°C ~ 45°C |
Discharging: -20°C ~ 55°C | |
Storage Temperature | Recommended to store 20 ± 5°C for long term storage |
Cycle Life | Over 2000 times (80% of initial capacity at 0.2C rate, IEC Standard) |
